AutoCAD 2020: 3D Drawing and Modeling (Mixed Units): Autodesk Authorized Publisher - Paperback

by Ascent -. Center for Technical Knowledge (Author)

The AutoCAD^(R) 2020: 3D Drawing and Modeling guide introduces users, who are proficient with the 2D commands in the AutoCAD^(R) software, to the concepts and methods of 3D modeling. The guide provides a thorough grounding in the fundamentals of 3D and explores the main features of the advanced 3D Modeling workspace in the AutoCAD software.

Topics Covered

• 3D viewing techniques
• Working with simple and composite solids
• Creating complex solids and surfaces
• Modifying objects in 3D space
• Editing solids
• Creating sections, camera perspectives, and animations
• Working with point clouds
• Converting 3D objects
• Setting up a rendering with materials and lights
• Creating 2D drawings from 3D models
• Working with the User Coordinate System
• Set up a drawing for 3D Prints

Prerequisites

• Access to the 2020.0 version of the software, to ensure compatibility with this guide. Future software updates that are released by Autodesk may include changes that are not reflected in this guide. The practices and files included with this guide might not be compatible with prior versions (i.e., 2019).
• A good working skill level in the AutoCAD software, i.e. a minimum of 80 hours of work experience with the AutoCAD software, is recommended.
