Autodesk Inventor 2020: Introduction to 2D Milling (Mixed Units): Autodesk Authorized Publisher - Paperback

by Ascent - Center for Technical Knowledge (Author)

The Autodesk^(R) Inventor^(R) 2020: Introduction to 2D Milling guide focuses on instructing new users on how to use the Inventor CAM add-on to create 2D milling toolpaths. The guide begins with an introduction to the overall Inventor interface and explains how to manipulate your 3D model to change its orientation and view display. Through additional hands-on, practice-intensive curriculum, you will learn the key skills and knowledge required to take the 3D model, set it up in the CAM environment, and assign the toolpaths needed to generate the CNC code required by 2D milling machines.

Topics Covered

• Navigate the Inventor software interface to locate and execute commands.
• Use the model orientation commands to pan, zoom, rotate, and look at a model.
• Assign visual styles to your models.
• Locate, modify, and create tools in the Tool Library.
• Set up machining operations using Inventor CAM.
• Create a Face, 2D Adaptive, 2D Pocket, 2D Contour, and Drill toolpath using the Inventor CAM interface.
• Use the Simulation option to visualize toolpaths.
• Import a tool library.
• Create a toolpath template.
• Post process an Inventor CAM setup to output the CNC code required to machine a model.

Prerequisites

• Access to the 2020.2 version of the software, to ensure compatibility with this guide. Future software updates that are released by Autodesk may include changes that are not reflected in this guide. The practices and files included with this guide are not compatible with prior versions (e.g., 2019).
• As an introductory guide, Autodesk(R) Inventor(R) 2020: Introduction to 2D Milling does not assume prior knowledge of Autodesk Inventor CAM. However, this guide will not provide instructional content on how to create 3D models using the Inventor modeling tools. Its focus is solely on generating 2D milling toolpaths once models are created. The Autodesk(R) Inventor(R) 2020: Introduction to Solid Modeling guide should be used to learn to create 3D models.
• It is recommended that users have prior experience with the Windows operating system, knowledge of 3D model creation/modification, and an understanding of the CNC milling process.
