Basic Fixture Design - Paperback

by Paul Campbell (Author)

This lavishly illustrated introduction to fixture design takes the reader from concept to building. It details the mechanics, materials used, commercially available components, design procedures, and economics.

Features

• Uses basic terms to explain fixture design.
• Focuses on actual tooling procedures throughout.
• Provides a full understanding of the design and application of fixture tools and checking fixtures, welding fixtures and procedures, three-dimensional space in checking compound warped surfaces, measurement systems, and the simple mathematics required.
