Catia V5-6r2018: Generative Drafting (ANSI) - Paperback

by Ascent -. Center for Technical Knowledge (Author)

The CATIA V5-6R2018: Generative Drafting (ANSI) learning guide enables you to use the generative capabilities of CATIA V5 to create an ANSI drawing from a 3D solid Part. This course is appropriate for new CATIA V5 users.

Topics Covered

• Start a generative drawing
• Define the main views
• Define section views and cuts
• Define secondary views: detail, clipping, broken, breakout, auxiliary, isometric and unfolded views
• Edit a view and sheet properties
• Add sheets to a drawing
• Reposition views
• Modify section, detail and auxiliary profiles
• Modify section, detail and auxiliary graphical definitions
• Modify section hatching representations
• Create generative dimensions and tolerances
• Generate assembly drawings
• Create annotations and drawing tables
• Create balloons
• Check links to a solid 3D part and update a drawing
• Add a title block
• Print the drawing
• Set drafting options

Prerequisites

• CATIA V5-6R2018: Introduction to Modeling, or
• CATIA V5-6R2018: Introduction for Non-Designers
