Creo Parametric 5: 0: Advanced Part Design - Paperback

by Ascent -. Center for Technical Knowledge (Author)

As an experienced user in the basics of Creo Parametric 5.0, Creo Parametric 5:0: Advanced Part Design enables you to become more productive by extending your modeling abilities with advanced functionality and techniques. This extensive hands-on learning guide contains numerous labs and practices to give you practical experience that will improve your job performance.

Topics Covered

• Advanced datum features
• Advanced bends
• Sweeps with variable sections and helical sweeps
• Rotational and swept blends
• Designing with rounds
• Advanced round functionality
• Drafts
• Basic surface design
• Part family tables
• User-defined features (UDFs)
• Date sharing
• View Manager
• Automation (Appendix)

Prerequisites

• Access to the Creo Parametric 5.0 software. The practices and files included with this guide might not be compatible with prior versions. Practice files included with this guide are compatible with the commercial version of the software, but not the student edition.
• Completing Creo Parametric 5.0: Introduction to Solid Modeling, or the equivalent Creo Parametric experience.
