Creo Parametric 5.0: Sheet Metal Design - Paperback

by Ascent -. Center for Technical Knowledge (Author)

Creo Parametric 5.0: Sheet Metal Design enables you to use your introductory modeling skills to create sheet metal models, including walls, bends, notches, and form features. On completion of this course, you will have acquired the skills to confidently manipulate sheet metal geometry, adjust bend developed lengths, and convert solid parts.

Creo Parametric 5.0: Sheet Metal Design was developed against Creo Parametric 5.0.3.0.

Topics Covered

• The sheet metal environment
• Primary and secondary walls
• Bend relief
• Corner relief
• Regular unbends, back bends, and cuts
• Notches and punches
• Bend features
• Unbending complex geometry
• Sheet metal forms
• Documenting a sheet metal part
• Converting solid parts
• Sheet metal setup
• Investigating a sheet metal part

Prerequisites

• Access to the Creo Parametric 5.0 software. The practices and files included with this guide might not be compatible with prior versions. Practice files included with this guide are compatible with the commercial version of the software, but not the student edition.
• Completion of Creo Parametric: Introduction to Solid Modeling, or similar levels of prior experience using the Creo Parametric software.
