Creo Parametric 6.0: Behavioral Modeling - Paperback

by Ascent - Center for Technical Knowledge (Author)

The Creo Parametric 6.0: Behavioral Modeling learning guide introduces the analysis tools available in the Behavioral Modeling Extension (BMX) for establishing and analyzing design goals. You will learn how to create analysis features and sensitivity and feasibility studies. Behavioral Modeling provides the ability to automatically change dimensions and parameters to meet specific design goals.

This guide was developed using Creo Parametric 6.0, Build 6.0.4.0.

Topics Covered

• Capabilities of BMX
• Analysis Features
• Sensitivity Analysis
• Feasibility and Optimization Analysis
• Multi-Objective Design Studies
• Graph Matching
• Excel Analysis
• Motion Analysis

Prerequisites

• Access to the Creo Parametric 6.0 software. The practices and files included with this guide might not be compatible with prior versions. Practice files included with this guide are compatible with the commercial version of the software, but not the student edition.
• It is highly recommended that you have completed the Creo Parametric 6.0: Introduction to Solid Modeling. Experience with MS Excel and Creo Mechanism Design is useful, but not required.
