Creo Parametric 6.0: Working with 3D Annotations and Model-Based Definition - Paperback

by Ascent - Center for Technical Knowledge (Author)

In this course, you will gain an understanding of the general concepts behind Model-Based Definition (MBD) and why your company is likely moving toward its implementation. You will learn the 3D Annotation tools, which are necessary for using the Creo Parametric software to support Model-Based Definition.

Topics Covered

• Overview of Model-Based Definition
• The Annotation Interface
• Configuration and Detail Options
• Cross Sections
• Using Combination States
• Semantic and Presentation Annotations
• Working with Legacy Datums
• Adding Dimensions
• Adding Geometric Tolerances
• Adding Notes
• Note Libraries
• Adding Symbols

Prerequisites

• Access to the Creo Parametric 6.0 software. The practices and files included with this guide might not be compatible with prior versions. Practice files included with this guide are compatible with the commercial version of the software, but not the student edition.
• It is highly recommended that you have completed the Creo Parametric 6.0: Introduction to Solid Modeling course. This content was developed using Creo Parametric 6.0, Build 6.0.4.1.
