Jig and Fixture Design Manual - Hardcover

by Eric Karl Henriksen (Author)

Written for the experienced engineer as well as the student, this classic reference comprehensively presents the fundamental aspects of jig and fixture design in a readable manner.

Features

• Presents the fundamental principles for combining the components into successful fixtures.
• Includes metric conversion tables and appendices on transfer of tolerances, measuring of tolerances, measuring of angles in radians, and the dimensioning of fixtures by stress analysis.

Back Jacket

The book is written as a textbook and reference source, and is meant to be used by the experienced practitioner as well as the beginner, whether he is a technician in industry or a college student.
